Automatic soldering machine
DIXON automatic soldering machines can conduct processes like spot soldering, drag soldering, round piece soldering and soldering of irregular shapes. They control the feeding systems programmatically and can perform automatic solder wire conveying with constant quantity and at constant speed, to realize intelligent and controlled operation, solve uneven soldering joints and inveracious soldering in manual soldering, improve the efficiency, reduce the labor force, and guarantee the soldering quality.
Batch tin-free soldering
The temperature controllers are based on the principle of heating by high frequency eddy current to realize batch tin-free soldering of products.
Storable operation procedures
The operation procedures can be stored in the machines, each of which can be used for soldering different products of various shapes.
Precision motor driving
The robotic arms of the machines are all molded and cast from aluminum profile, with multi-axis linkage and precision stepper motor driving.
Dual-brush tip cleaner
With the exclusively researched and developed dual-brush tip cleaners, the soldering heads can be cleaned promptly, the soldering processing quality can be stable, and the soldering tips can have longer service lives.
| Model | 331 | 441 | 531 | 641 | |
| 331R | 441R | 531R | 641R | ||
| Stroke | X | 300mm | 400mm | 500mm | 600mm |
| Y | 300mm | 400mm | 500mm | 600mm | |
| Z | 100mm | ||||
| R | 340 | ||||
| Speed | X-Y-Z-R | 5-600mm/sec | |||
| Repetition accuracy | X-Y-Z-R | ±0.01mm | |||
| Load | 6kg | ||||
| Tool load | 3kg | ||||
